H80 High-Speed High-Precision Gear Hobbing Machine
by Paramount · Suzhou, Jiangsu · H80/H120/H150 series
A compact CNC gear hobbing machine for small gears up to 80 mm diameter, with a direct-drive hob head and torque-motor work table. Fully enclosed for fast chip removal.
Key specs
Weight
5,000 kg11,023 lb
Power
11 kW
Get a delivered price for your plant
Tell us the country, voltage and quantity. Our team in Austin and Bogotá checks certification, lead time and service with Paramount, then sends you a quote in USD.
English or Spanish · No cost to request · Quotes in USD
Full specifications
| Max machining diameter | 80 mm |
|---|---|
| Max machining module | 3 |
| Max travel of pallet | 220 mm |
| Range of machining teeth | 3-999 |
| Hob holder rotation angle | ±45° |
| Max hob diameter | 80 mm |
| Hob bar diameter | 13 mm |
| X and Y pump fast moving speed | 10 m/min |
| Work spindle max speed | 1000 r/min |
| Work spindle torque motor rated torque | 95 N.m |
| Hob spindle max speed | 5000 r/min |
| Hob spindle rated power | 11 kW (electric spindle) |
| Numerical control system | FANUC |
| Spindle motor, servo motor | FANUC |
| Machine weight | 5000 kg |
| Overall dimensions (L x W x H) | 2200 x 2040 x 2127 mm |
As printed in the Paramount catalog, page 1. Confirm final specs in your quote.
What it does well
- Direct-drive hob head and table
- Fully enclosed machine interior
- Can machine HRC58-62 hard gears
- Fanuc CNC as standard
Applications
Small and medium gear hobbingHard gear hobbingHarmonic drive flexspline machining
Industries
Gear manufacturingRobot reducer production
