YIG-D400 Delta Parallel Robot Feeding System
by YIG · Shenzhen, Guangdong · YIG delta parallel robots
Complete small-parts pick and place cell: vibratory hopper, flexible vibratory tray, upper and lower cameras and a 3-axis delta arm. Built for light parts up to 0.2 kg.
Tell us the country, voltage and quantity. Our team in Austin and Bogotá checks certification, lead time and service with YIG, then sends you a quote in USD.
English or Spanish · No cost to request · Quotes in USD
Full specifications
| Max working radius | R200 mm |
|---|---|
| Max gripping weight | 0.2 kg |
| Overall dimensions (L x W x H) | 533 x 384 x 697 mm |
| Power supply | AC220V, 50Hz, 1 kW |
| Air pressure | 0.5 to 0.7 MPa |
| Total weight | Approx. 75 kg |
| Tray dimensions (L x W x H) | 240 x 180 x 10 mm |
| Flexible vibratory tray dimensions (L x W x H) | 220 x 140 x 145 mm |
| Hopper capacity | 1.5 L (can be made larger) |
| Efficiency | Subject to physical testing |
As printed in the YIG catalog, page 3. Confirm final specs in your quote.
What it does well
- Upper camera locates parts, lower camera checks bottom features
- Flexible vibratory tray orients parts for picking
- Hopper size can be made larger on request
